EK-151S Product Description:

Features:

The EK-151S is a high-performance stage monitor with built-in two-way two-unit structure, providing a frequency range of 55Hz-20kHz, consisting of a 15-inch low-frequency and a 1.75-inch high-frequency compression driver, using customized driver and waveguide technology, its 90° x 60° constant directive diffusion angle can accurately cover the stage area, and the monitoring angle is matched with two angles of 55°/20°, and the bottom has rubber feet to provide anti-slip effect.

Applications: distributed systems, cruisers, concert halls, theaters.

Technical Parameters:

UNIT CONFIGURATION: LF: 1×15" (385MM); HF：1×1.75"（44.4MM）

Frequency response: 55Hz-20KHz

System: 2way speaker

Impedance: 8ohm

Sensitivity 1w/1m: 96dB

Rated/Peak Power (RMS): 450W/1800W

Output SPL (continuous/peak): 121dB/127dB

Dispersion Angle: 90＆#8304;x60＆#8304; (H x V)

Protection circuit: highly intelligent electronic protection system

Input interface: 2× Speakon NL4MP

Color: Black

Cabinet material: birch surface multi-layer plywood

Surface treatment: water-based polyurethane spot paint

Product size: width 660× height 520× depth 425MM

Product net weight: 26KG
